Description
Joining the PRO-65 and PRO-80 in the expanded PRO-IC range, the new PRO-80LV 70/100V line speaker offers similarly stealthy but highly flexible system options for commercial installations. Reprising many of Monitor Audio’s most acclaimed hi fi design configurations, its 8”
mmp II bass driver and signature 1” gold-dome tweeter deliver high audio quality with excellent speech intelligibility for public address and distributed music applications.
The PRO-80LV features an internal matching transformer, providing a 70V or 100V input for powering multiple speakers on a single amplifier channel. A 16 ohm switch position offers the flexibility to wire one, two, three or four speakers in parallel per channel. Power taps allow system designers to set maximum SPL in areas such as restrooms and foyers.
Building regulations are satisfied by the PRO-80LV’s fireproof steel back box and secure anchor points while a plug-type connection block ensures easy and reliable system integration with a link out option for ‘daisy chain’ wiring. Combining installation versatility with Monitor Audio’s robust build quality and hi-fi clarity, the slender new PRO-80LV offers the added advantage of trimless aesthetics for an optimum blend of design, performance and value.
Only Available in packs of four
Technology
- mmp®II driver.
- This model features dust protection covers that are designed to prevent the ingress of dirt or dust into the driver and crossover.
- Applications: Office complex, PA, multi-speaker background music applications such as for shopping areas.
- Only available in packs of four.
Specification
Frequency Response: 65Hz – 25KHz
Power Handling (RMS): 40 W
Mounting Depth: 101mm
Overall Diameter(including grille): 294mm
Impedance (nominal): 16Ω 70V (4,8, 16,32,64 W) 100V (8,16,32,64 W) power selection
Recommended Amp Requirements: 10 - 40 W
Overall Depth:(including grille): 113mm
Sensitivity (1W@1M): 87 dB
Drivers Unit Complement:
- 8” mmp® II cone bass-mid driver
- 1 x 25mm (1”) fabric soft dome tweeter
Cut-Out Diameter: 266mm
Construction Material: ABS (UL94 rated, RoHS2 Compliant) Painted steel grille, Steel rear enclosure
Maximum SPL (@1M. Installed/in room): 103.8 dBA
Pre-Construction Bracket: CB8-LV
Fixing Type: 4 position dog leg fixings
Connection: Screw type plug termination
Other Fire Rating: UL1480 & UL2043
