Description
The Lift System Light (LSL) is the smallest mechanism in our Lift System range suited to screens approximately 29" - 40". This range has been designed and developed to be a versatile solution to the rapidly growing variety of residential and commercial screens in todays market. It is available with the following lid types to cater for any situation.
Lid Types
PUSH FLAP (LSL-PF)
As the lift raises there is a roller that manually pushes the flap open, closing when the lift lowers with gravity.
ELECTRIC FLAP (LSL-EFA
Before the lift raises, a motorised arm pushes the lid open, closing after the lift lowers
BOX ENCLOSURE (LSL-BE)
Suitable for a box enclosure surrounds the screen or a floating lid that raises with the lift. (Not included)
- Quiet and Smooth Action at Approximately 40mm(1.6") per second
- Full Cable Management
- Wide Range of Mounting Options
- 24V DC motor - suitable for direct DC supply
- Marine Suitable Robust Beam
|
PRODUCT CODE
|
LSL1
|
LSL2
|
LSL3
|
|
CONTROL BOX
DIMENSIONS
|
150 X 210 X 50MM
(5.9 X 8.26 X 1.96")
|
150 X 210 X 50MM
(5.9 X 8.26 X 1.96")
|
150 X 210 X 50MM
(5.9 X 8.26 X 1.96")
|
|
CONTROL OPTIONS
|
RS232 / CONTACT CLOSURE / IR (RF
AVAILABLE)
|
RS232 / CONTACT CLOSURE / IR (RF
AVAILABLE)
|
RS232 / CONTACT CLOSURE / IR (RF
AVAILABLE)
|
|
DECIBEL RATING
|
58DB
|
58DB
|
58DB
|
|
FINISH (CUSTOM
AVAILABLE)
|
BLACK PAINT - RAL 9005
|
BLACK PAINT - RAL 9005
|
BLACK PAINT - RAL 9005
|
|
INTERNAL CABINET
HEIGHT
|
580MM (22.83")
|
694MM (27.32")
|
769MM (30.27")
|
|
LID TYPE
|
BOX ENCLOSURE & FIXED LID OPTIONS
SUPPLIED
|
BOX ENCLOSURE & FIXED LID OPTIONS
SUPPLIED
|
BOX ENCLOSURE & FIXED LID OPTIONS
SUPPLIED
|
|
MAX LIFTING
CAPACITY
|
25KG (55LBS)
|
25KG (55LBS)
|
25KG (55LBS)
|
|
MAX LIFTING
CAPACITY (MARINE)
|
16KG (35LBS)
|
16KG (35LBS)
|
16KG (35LBS)
|
|
MAX SCREEN HEIGHT
|
410MM (16.14")
|
524MM (20.62")
|
599MM (23.58")
|
|
MOVEMENT TYPE
|
MOTORISED
|
MOTORISED
|
MOTORISED
|
|
OUTPUT POWER
SUPPLY
|
YES(12V)
|
YES(12V)
|
YES(12V)
|
|
POWER CONSUMPTION
|
250 - 500W
|
250 - 500W
|
250 - 500W
|
|
POWER SUPPLY
|
240V OR 110V
|
240V OR 110V
|
240V OR 110V
|
|
SCREEN SIZES
(APPROX)
|
19-32"
|
32-40"
|
40"
|
|
SHIPPING
DIMENSIONS
|
92 x 55 x 25cm (36.22 x 21.65 x
9.84")
|
92 x 55 x 25cm (36.22 x 21.65 x
9.84")
|
105 x 55 x 25cm (41.33 x 21.65 x
9.84")
|
|
SHIPPING WEIGHT
|
15kg (33lbs)
|
18kg (40lbs)
|
20kg (44lbs)
|
£1,375.00 excl. VAT
Available for online purchase for Home delivery via Courier or Direct from Manufacturer/Distributor.
